Other information
- LFP Lithium-ion Battery Module
- Wireless Charger
- Solar Charging
- Integrated Fast Charging 1h 80%
- Parallel Connector
- EPS Emergency Power Supply
TECHNICAL DATA
Output Specifications
Output Power:
1200 W
Peak Power (1.5 s): 2400 W
Frequency: 50 Hz
Voltage: 230 V
Phases: 1
Battery Specifications
Battery: Li-ion LFP
Battery Nominal Voltage: DC 25.6
Battery Design Life at 80%: 2000 cycles
Battery Nominal Capacity: 1075 Wh
Input Specifications (PWB Charging)
Maximum Single-phase Input: 800 W
Charging Time to 80%: 1 h
Charging Time to 100%: 2 h
Maximum Solar DC Charging: 400 W
DC/Solar Charging Time to 80% (with 400 W solar panels under optimal sunlight conditions): 2.1 h
DC/Solar Charging Time to 80% (with 200 W solar panels under optimal sunlight conditions): 4 h
Car Cigarette Lighter Charging (12 V DC): A 8
Car Cigarette Lighter Charging Time to 80%: 11 h
Installation Data
Length: 376 mm
Width: 215 mm
Height: 262 mm
Weight: 16 Kg
Discharge Temperature Range: -10...40 °C
Charging Temperature Range: 0...40 °C
Box Dimensions LxWxH: 455 x 295 x 365 mm
Ports
Schuko AC Sockets 230V: 2
Car Socket (DC 12V/10A): 1
DC 6514 (12 V/5): 2
USB-A 12 W max (V/2.4 A): 2
Fast USB-A 24 W max (5/9/12 V | 3/2.2/2 A): 2
USB-C max 100 W (5/9/12/15/20 V | 3/5 A): 2
Wireless Charging: 1
