Other information
- LFP Lithium-Ion Battery Module
- Wireless Charger
- Solar Charging
- Built-in Fast Charging 1h 80%
- Parallel Connector
- EPS Emergency Power Supply
TECHNICAL DATA
Output Specifications
Output Power:
2400 W
Peak Power (1.5 s): 4800 W
Frequency: 50 Hz
Voltage: 230 V
Phases: 1
Battery Specifications
Li-ion Battery: LFP
Nominal Battery Voltage: 51.2 VDC
Battery Design Life at 80%: 2000 cycles
Nominal Battery Capacity: 2150 Wh
Input Specifications (PWB Charging)
Maximum Single-Phase Input: 1800 W
Charging Time to 80%: 1 h
Charging Time to 100%: 2 h
Maximum DC Solar Charging: 400 W
DC/Solar Charging Time to 80% (with 400 W solar panels and optimal sunlight conditions): 5 h
b) DC/Solar Charging Time to 80% (with 200 W solar panels and optimal sunlight conditions): 8 h
Car Cigarette Lighter Charging (12 V DC): A 8
Charging Time with Car Cigarette Lighter to 80%: 19 h
Installation Data
Length: 496 mm
Width: 266 mm
Height: 350 mm
Weight: 29 Kg
Discharge Temperature Range: -10...40 °C
Charging Temperature Range: 0...40 °C
Box Dimensions LxWxH: 620 x 380 x 490 mm
Ports
Schuko AC Outlets 230V: 4
Car Socket (DC 12V/10): 1
DC 6514 (12 V/5): 2
USB-A 12 W max (5 V/2.4): 2
Fast USB-A 24 W max (5/9/12 V | 3/2.2/2): 2
USB-C max 100 W (5/9/12/15/20 V | 3/5): 2
Wireless Charging: 2
