Stihl MSA 220 TC-O Battery Chainsaw

Compatible with AP series batteries

• High cutting capacity and great comfort for tree care, gardening and landscaping work, as well as for municipal administrations
• In tree care, it stands out for its powerful EC motor
• The oil sensor, which continuously measures the amount of chain lubricant oil, helps you work efficiently. In case of low oil, you will be alerted via the LED indicator
• Usage is particularly intuitive thanks to the electronic control system with status LED; this also supports the mechanical chain brake, which also features a status LED.
• In a 180° display cockpit, the LEDs are grouped so you are always quickly informed about the status of your tree care chainsaw
• The chainsaw is secured to the wood by a robust metal toothed claw, allowing precise cuts with ease. Additionally, the toothed stop can be quickly replaced
• The cooling air is cleaned by a fleece filter, protecting the electronics and motor parts in the long term. The cooling air filter can be cleaned quickly and effectively
• In case of intensive use or a draining battery, the power electronics automatically reduce the current and thus the torque via de-rating. This allows you to complete a cut, while other saws in a comparable situation would already shut down
• Bar length: 30 / 35 cm
• Weight: 3.3 kg
• Rated voltage: 36 V
• Recommended battery for optimal performance: AP 300 S
• Number of cuts (wood 10x10 cm) with battery AP 300 S: up to 290 cuts
• Operating time with battery AP 300 S: up to 24 minutes

Sold without battery and charger

30 cm bar and 3/8" P chain included
ROLLOMATIC E LIGHT bar 30 cm 3/8 P 1.3 mm 44 links
PS3 chain 3/8" P 1.3 mm 44 links

35 cm bar and 3/8" P chain included
LIGHT P04 bar 35 cm 3/8 P 1.3 mm 50 links
PS3 chain 35 cm 3/8 P 1.3 mm 50 links

TECHNICAL DATA

CHAINSAW
Rated voltage: 36 V
Max voltage: 40 V
Power consumption: 2.10 kW
Power output: 1.70 kW
Battery system: AP
Weight without battery: 2.7 kg
Bar length: 30 / 35 cm
Groove width: 1.30 mm
Chain pitch: 3/8" P
Protection rating: IPX4
Sound pressure level: 94 dB(A)
Sound power level: 104 dB(A)
Vibration value left: 3 m/s²
Vibration value right: 3.4 m/s²

BATTERY
Recommended battery: AP 300 S
For sawing squared wood (10x10 cm) with battery AP 20: up to 16 minutes
For sawing squared wood (10x10 cm) with battery AP 20: up to 100 cuts
For sawing squared wood (10x10 cm) with battery AP 30: up to 23 minutes
For sawing squared wood (10x10 cm) with battery AP 30: up to 280 cuts
For sawing squared wood (10x10 cm) with battery AP 200 S: up to 21 minutes
For sawing squared wood (10x10 cm) with battery AP 200 S: up to 130 cuts
For sawing squared wood (10x10 cm) with battery AP 300 S: up to 24 minutes
For sawing squared wood (10x10 cm) with battery AP 300 S: up to 290 cuts
For sawing squared wood (10x10 cm) with battery AP 500 S: up to 34 minutes
For sawing squared wood (10x10 cm) with battery AP 500 S: up to 340 cuts

EQUIPMENT

Velcro filter
The velcro air filter of the new MSA 300 ensures consistent performance, even under the highest loads. Its extremely fine-pored filtering material keeps even the finest dust and dirt away from the power electronics and electric motor. To clean, spray the removed air filter with STIHL Varioclean, after a short waiting time wash it with lukewarm water and let it dry. It is then ready for use again

Control panel and notifications
The MSA 300 features an electronic control and notification cockpit with an LED display. It offers the user three selectable operating modes and allows easy and safe operation of the machine. Additionally, thanks to the large LED display, the user always has all important information about the chainsaw's status at a glance, such as the chainsaw or chain brake status

Side chain tensioner
The chain is tensioned laterally via the drum. This avoids any contact between the operator's hand and the cutting chain

Oil sensor
The LED display of the oil sensor provides reliable information about the chain oil fill level. If the LED is off, there is oil in the system. Red indicates a lack of chain oil
