Noleggio Isuzu SNAKE 2413 plus platform - RENTAL
Code: CUS-52562
Other information
- The Oil&Steel Snake 2413 Plus Aerial Platform has been developed to best meet the needs of operating in metropolitan environments
- In fact, the truck-mounted platform can reach a working height of approximately 23.5 meters
- With a reach extending up to 12.6 meters, the platform has a load capacity of 250 kg
- Compact dimensions
- Lightweight and stability
- Precision and safety of movements
- Height from 20 to 24 m
The main features of this machine are:
TECHNICAL DATA
Max working height for 1 operator:
23.5 m
Platform height for 1 operator: 21.5 m
Max working outreach for 1 operator: 12.6 m
Load capacity for 1 operator: 80 Kg
Load capacity for 2 operators: 250 Kg
Height at rest: 2700 mm
Length at rest: 6300 mm
Width at rest: 2100 mm
Superstructure rotation: 400°
Platform: 1400 x 700 x h1100 mm Aluminum
Controls Aerial part: electro-hydraulic - Stabilization: electro-hydraulic (or hydraulic)
Platform rotation: 90° right + 90° left
Scissor arm: Double steel bar
Stabilizers: H-type. Electro-hydraulic, hydraulic or manual crossbeam extension
Minimum installation: 3.5 t
