Stihl Cordless Drill BTA 140

Compatible with AP series batteries

• With the STIHL BTA 140 battery auger from the STIHL AP system, it is possible to drill holes up to 300 mm in diameter
• This makes the STIHL BTA 140 ideal for professional applications in gardening and landscaping, forestry and agriculture, as well as in the construction sector
• The battery auger allows for the installation of posts, digging planting holes and drainage trenches, or creating small to medium-sized foundations quickly and efficiently. The sharp bits and cutting blade chucks of the auger effectively penetrate even rocky soils
• The high-performance EC motor operates virtually wear-free. It features smooth operation and reduced vibrations. Thanks to its quietness, hearing protection is not required during work
• The STIHL BTA 140 drill is designed for single-person use. Its excellent balance and drilling axis positioned close to the body allow for comfortable, ergonomic, and fatigue-free use. The battery drill offers three operating modes: slow for easy, low-recoil drilling; fast for tough soils; and reverse to free stuck bits. The desired operating mode is activated via the handle and displayed on the integrated screen
• Thanks to the wide and comfortable ergonomic padding, the drill can be guided smoothly and precisely. If the STIHL BTA 140 drill jams during operation, the STIHL QuickStop system automatically detects the torque and stops drilling. Work can be resumed immediately by reactivating the drill via the control handle.

TECHNICAL DATA

DRILL

Rated voltage: 36 V
Maximum voltage: 40 V
Power consumption: 2.10 kW
Output: 1.70 kW
Spindle speed 1st gear: 170 rpm
Spindle speed 2nd gear: 230 rpm
Spindle speed reverse: 35 rpm
Device weight: 7.6 kg
Device width: 375 mm
Device height: 285 mm
Device length: 555 mm
Sound pressure level: 80 dB(A)
Sound power level: 91 dB(A)
Vibration value left: 2.4 m/s²
Vibration value right: 2.6 m/s²
Protection class IP: IPX4

BATTERIES

Battery system: AP
Recommended battery: AP 300 S
Minimum number of holes per charge with battery AP 200 S: 100
Maximum number of holes per charge with battery AP 200 S: 150
Minimum number of holes per charge with battery AP 300 S: 150
Maximum number of holes per charge with battery AP 300 S: 230
Minimum number of holes per battery charge AP 500 S: 180
Maximum number of holes per battery charge AP 500 S: 270

EQUIPMENT

Constant Power
REGARDLESS OF THE BATTERY CHARGE LEVEL. With other brands of battery-powered tools, performance typically decreases as the battery discharges during use. This does not happen with STIHL battery-powered tools equipped with CONSTANT POWER. Thanks to intelligent electronics, your STIHL tool always operates at high performance.

Ergonomic Grip
FOR OPTIMAL HOLD. The large support pad allows smooth and precise drilling. The pad rests comfortably against the body during drilling, providing optimal support and precise guidance.

Stihl QuickStop System
FOR SAFE WORKING. The STIHL QuickStop system automatically stops drilling as soon as it detects a twist of the drill bit. This usually occurs when the bit jams. The system ensures the drill stops immediately in this case. Once the jam is removed or the bit is loosened by turning it counterclockwise, the drill can be reactivated via the grip and drilling can resume.

QuikStop System Transport Compartment
PROTECTED TRANSPORT. The STIHL QuickStop system stop lever can be folded and locked for transport, reducing bulk during storage. Additionally, the compact design of the STIHL QuickStop transport bracket protects all system components from impacts during transport.

EC Motor
LOW MAINTENANCE AND EFFICIENT. Thanks to its compact design, lightweight, and high efficiency, the EC motor enables low energy consumption operation. Additionally, this motor boasts a long lifespan.
