Other information
- Anti-tip
- Fully metal panels and bumpers
- Foldable ROPS and lap belt
- Maximum working slope 25° / 47%
- Reinforced puncture-proof tires
- LED headlight with depth lights
TECHNICAL DATA
Weight: 445 kg
Engine: Honda GX690 (24HP)
Transmission: Hydro-mechanical with auxiliary tank
Drive: 2 and 4 wheel drive with differential lock
Cutting: Oscillating blades with cardan shaft transmission
Cutting width: 975 mm
Cutting height: 0 - 170 mm
Brakes: Internal expansion
Turning radius: 1.8 m
Max cutting capacity: 7,300 m2 /h
Overall length: 1,950 mm
Overall width: 1,055 mm
Overall height: 1,725 (1,040) mm
Displacement: 688 cm3
Starting system: Electric
Speed: 0-13.8 km/h
